Heat Dissipating Nano Copper Foil Sheet for PCB High Conductive Carbon Coated
Copper foil sheet products introduction
Shanghai Metal Corporation is an international manufacturer and supplier for copper sheet. We produce slitting, edging, and oscillate winding copper to fit your specific requirements.
We are capable of producing a wide variety of precision strip products to special requirements, geared to handle high volumes with tight tolerances. Continuous strip-casting machines produce long, weld-free coils of uniform composition and properties, and automatic electronic gauge-controls maintain consistent thickness.
Quick Details Description
| Application: | Electrical, Electronic,shield/roofing,MRI scanning room |
| Thickness range: | 0.1mm~200mm |
| Shape: | coil,roll |
| Width range: | 20~2500mm |
| Material: | Brass |
| Grade: | Nano Carbon Copper Foil, Pure Copper |
| Cu (Min): | 99.90% |
| Ultimate Strength (≥ MPa): | 220--400 |
| Elongation (≥ %): | 35 |
| Surface: | Polished |
| Sample | Free |
Copper Copper Foil Physical Property
Density: 8.9g/cm3
Electrical conductivity (20°C): min 90%IACS for annealed to temper min 80%IACS for rolled to temper
Thermal conductivity (20°C): 610W/(m°C)
Elastic modulus: 118000N/m
Softening temperature: ≥380°C
Copper Foil Applicantion
Widely used for copper foil for transformers, digital cameras, cell phones, DVD, HVD precision electronic products, computer communications, wires, cables, high-frequency transmission, isolation, electromagnetic interference. Circuit
turns the path, because of excellent electrical conductivity of copper, used for low attenuation requirements, performance
is better than copper foil mylar and other high-frequency attenuation: 10-25GHz.
Copper Foil Products Picture
Packaging Details:
A: Inner Packing:
Cut roll: printed core and shrink wrapping
Original roll: cardboard wrapping
B: Outer Packing:
Cut roll: carton
Original roll: carton + pallet / wood case
Detail Introduction
| Material | Copper foil, Nanocarbon, Thermal materials |
| Color | Black/Copper |
| Grade | SGS, ROHS, Reach |
| Used | Thermal conductive, high temperature, Led, PC, Heat sink...etc |
| Thickness | 55um, 75um |
| Thermal Conductivity | 560w/mk |
| Material | Nano Carbon |
| Brand | KINGBALI |
| Usage | Electronic products ,Digital products,Cell phone products,Auto Industry. |
| others | The size and shape can as customer requirement. |
| Best die-cut Nano Carbon Material Sheet to mount various of precison molded parts. |
| Features | 1.Excellent resistance to heat (dry air), at +260º C continuous and +260º C intermittent.Remains flexible at low temperatures of -40ºC. |
| 2.Resistant to ultra-violet light, ozone and weathering processing,pharma ceutical and cosmetic manufacturing area. |
| 3.Good electrical insulation properties |
| 4.Keep constant even at high temperatures. |
| 5.Resistance to chemicals; moderate resistance to general chemical products. |
| Sample | Free samples & Freight Charges will be returned after deal. |
| Lead time | 15 workdays for Nano Carbon Material Sheet |
| Delivery | FOB Shanghai ,CFR,CIF |
| Payment | L/C or TT |
